Shurflo 700 GPH Electric Bilge Pump Overview
The Shurflo 700 GPH Electric Bilge Pump offers a robust solution tailored specifically for marine requirements. They feature permanent magnet motors, ABS plastic (for 380–1000gph models) or nylon housings (for the 1500 and 2000gph models), and high-strength nylon impellers. With water-cooled motors to increase their lifespan, these pumps are performance-oriented and durable. They come equipped with a 3′ tinned wire lead for 380–1000gph models or a 6′ lead for the 1500 and 2000gph models. The 1500 and 2000gph models also include an easy-install swivel base.
Key Features
- Durable ABS plastic or nylon housing
- Swivel base included with 1500 and 2000gph models for easy installation
- Three-year warranty
Specifications
Pump Type: Centrifugal
Submersible: Yes
Built-in Switch: No
Case Material: Comprised of either ABS or nylon
Capacity, Amperage, Volts, Port Diameter, and Dimensions
| Capacity | Amperage | Volts | Port Dia. | Dimensions |
|---|---|---|---|---|
| 380gph | 1.7A @ 12V DC | 12V DC | 3/4″ | 4 3/16″H x 3 3/4″W |
| 500gph | 1.8A @ 12V DC | 12V DC | 3/4″ | 4 3/16″H x 3 3/4″W |
| 700gph | 3.2A @ 12V DC | 12V DC | 3/4″ | 4 3/16″H x 3 3/4″W |
| 1000gph | 3.2A @ 12V DC | 12V DC | 1 1/8″ | 4 3/16″H x 3 3/4″W |
| 1500gph | 8A @ 12V DC | 12V DC | 1 1/8″ | 7 3/16″H x 6″W |
| 1500gph | 4A @ 12V DC | 24V DC | 1 1/8″ | 7 3/16″H x 6″W |
| 2000gph | 10A @ 12V DC | 12V DC | 1 1/8″ | 7 3/16″H x 6″W |
| 2000gph | 5A @ 12V DC | 24V DC | 1 1/8″ | 7 3/16″H x 6″W |
More Information
- For installation instructions for 380-1000gph pumps, click here to see the data sheet.
- For installation instructions for 1500-2000gph pumps, click here to access the data sheet.
